Can be used for medium to heavy loads

The anchor has European Technical Approval for use in reinforced or unreinforced standard concrete with a strength class of min. C20/25 and max. C50/60 in accordance with EN 206-1:2000-12

Anchorage with European Technical Approval in cracked concrete (tension zone) and non-cracked concrete (compression zone)

The anchor may be used for anchorages with predominantly static loads (e.g. tare weight, fittings, stored materials) or quasi-static loads (e.g. railings)

Anchor size M8 to M10: Installation in dry or wet concrete

Anchor size M12 to M24: Installation in dry or wet concrete and in drill holes filled with water

For use in concrete

W-VIZ/HCR (HCR highly corrosion-resistant steel) can be used in particularly aggressive conditions. These conditions include e.g. constant changing immersion in salt water or in the splash zone range of salt water, atmospheres containing chlorine in swimming baths or atmospheres with extreme chemical contamination (e.g. flue gas desulphurisation systems or road tunnels in which de-icing agents are used)

Suitable for securing metal structures, metal profiles, brackets, foot plates, supports, railings, wood structures, beams etc.
