Female thread anchor W-VIZ-IG/S

Արտիկուլ: 5916112109

Գինը գրանցումից հետո

Հարցերի դեպքում կարող եք զանգահարել՝ +374(0)10 349347, 349348

0x - +	Գինը գրանցվելուց հետո	Ավելացնել զամբյուղ

- +

Գինը գրանցվելուց հետո

Կատալոգի էջը PDF ֆորմատով 1, 2, 3

Specification

Female thread anchor for injection system W-VIZ-IG. Individual attachment: Cracked and non-cracked concrete. Galvanised steel.

Standard threaded rods and screws can be used (see ETA-04/0095 for requirements)
High load-bearing capacities
Can be set flush with surface: Attached parts can be removed/remounted at any time
The injection anchor is suitable for cracked concrete (tension zone) and non-cracked concrete (compression zone)
Cured chemical injection mortar provides best possible seal for drill hole
Attachment with low expansion pressure allows minimal edge and axial clearance
The dimensions of the anchor rod enable safe expansion performance
Mechanical drill hole cleaning: Easy to use, excellent drill hole cleaning, high load-bearing capacities
Force-controlled/torque-controlled expanding galvanised steel anchor in sizes M6, M8, M10, M12, M16 and M20
The force is transferred via the mechanical teeth of individual cones in the composite mortar and also via a combination of retention and friction forces in the anchoring base (concrete)
